Specifications

• amazon bullet 1: Pergola kit includes: 9 base brackets, 4 3-arm post brackets, 4 4-arm post brackets and 1 5-arm post bracket (all for 4x4" wood posts) + 82 insert brackets for 2x4" wood slats + stainless steel screws (and screw caps) + complimentary drill bits
• amazon bullet 2: Freestanding pergola can be any size up to 24 feet x up to 24 feet (and 8-10 feet tall)
• amazon bullet 3: About our steel brackets: 1) 14-gauge steel (approximately 2mm thick) - 2) Laser-cut, bent and welded - 3) Advanced weather coating technology to withstand extreme weather conditions - 4) Pre-drilled holes for securing wood and accessories to brackets - 5) Backed by a 5-year warranty
• amazon bullet 5: Wood (lumber) and specialty hardware for anchoring base brackets to a secure base not included
• amazon bullet 4: The 82 insert brackets allow you to add 28 2x4 roof rafters to your pergola (7 rafters per roof quadrant) + 1 privacy wall with 13 2x4 slats
• coverage area sqft: 576
• Assembled Height Ft: 8
• Assembled Width Ft: 24
• Assembled Length Ft: 24
• Required Lumber: As noted above, wood (lumber) is NOT included in this pergola bracket kit (nor is the hardware you'll need to anchor the base brackets).Before you can build your pergola, you'll need to purchase the following items from a local building supply store or lumber yard:- Nine (9) 8' long 4x4 posts- Twelve (12) 12' long 4x4 posts- Forty-one (41) 12' long 2x4 slats- Anchoring hardware (36 pieces)The estimated cost* for the above lumber and anchoring hardware is $1012. Together with the cost of this Zen Pergolas bracket kit, your estimated total all-in cost for your pergola is $2911.*Estimate only - Actual cost will vary depending on the type of wood you buy, your location, local stores & availability and various other factors.
• Text Over Image - Dark: lumber not included
• Preconfigured Slat Spacing: between the roof and wall slats (see kit w/ far or close spacing) between roof/wall slats (see far or close spacing)
• Preconfigured Privacy Walls: see this same kit with no privacy wall or with 2 privacy walls see kit w/ no walls or w/ 2 privacy walls
• Preconfigured Roof: change roof to: canopies , 2x4s atop beams , 4x4 posts or angled 2x4s
• Roof Brackets Type: INSERT BRACKETS for 2x4 wood
• Max Roof Brackets Count: 82
• More Info About Kit: This pergola hardware kit with brackets for the outer frame, roof and one side wall will accommodate any free-standing pergola ranging from 13-24 feet by 13-24 feet . The contemporary wooden pergola does not need to be exactly 24' x 24' like in the images on this page. The kit includes 82 2x4 insert brackets . While the images on this page show that 56 of these brackets are used to add 28 straight inline roof rafters to your pergola (7 rafters to each of the four roof sections, all a 12' span with standard spacing between rafters) and the remaining 26 brackets are used to add one privacy wall with 13 slats (8' tall with standard spacing between slats), you can use the brackets any way you'd like (i.e. adding another privacy wall or half/partial wall, adding a side railing, installing the roof rafters and/or wall slats at an angle, etc.). You can also purchase additional 2x4 insert brackets here .
• Preconfigured Spacing Level: MED SPACING
• Preconfigured Wall Count: 1 PRIVACY WALL
• Preconfigured Roof Type: STRAIGHT 2x4s
• Required Lumber and Cost: As noted above, wood (lumber) is NOT included in this modern wood pergola building kit, nor is the hardware you'll need to anchor the base brackets to a secure foundation. Before you can build your modern-era pergola, you'll need to purchase the following items from a local building supply store or lumber yard (assuming you plan to build a 24' x 24' pergola that is 8' tall): Nine (9) 8' long 4x4 posts Twelve (12) 12' long 4x4 posts Forty-one (41) 12' long 2x4 slats Anchoring hardware (36 pieces) The estimated cost for the above lumber and anchoring hardware is $1,012 . This is only an estimate; actual costs will vary depending on the type of wood you decide to buy, your location, local stores & availability, and various other factors.
• Preconfigured Bracket Size: FOR 4x4s + 2x4s
• Pre Key Info Blocks: 4-Block
• Pre Key Info Brackets: 4x4 Frame
• Pre Key Info Roof: Slatted Roof (Straight Inline 2x4s)
• Pre Key Info Type: Freestanding
• Pre Key Info Walls: + 1 Privacy Wall
