Kit for a Pergola With Privacy Shade Walls
⬩ Freestanding 3-Block pergola with a 6x6 Frame
⬩ Slatted Roof (2x6s Atop Beams) + 3 Privacy Walls
About this Pergola Kit Configuration:
- Type: Free-standing (see the attached version of this kit)
- Bracket size: 6x6 (see the smaller 4x4 version of this pergola with privacy shade)
- Dimensions: Up to 12' wide x 36' deep (see the inverse up to 36' wide x 12' deep version of this kit)
- Roof style: Traditional w/ rafters atop beams (see this same kit with an inline, square posts or angled slats roof)
- Privacy wall(s): 3 (see this same kit with 0, 1 or 2 privacy walls)
- Roof/wall slat spacing: Medium (see this same kit with far or close spacing)
Want something completely different? Use our easy design tool to create your own pergola configuration.
Included in this Kit for a Pergola with Privacy Shade (3 Walls):
-
8x base brackets (for 6x6 wood) - 4x 3-arm post brackets (for 6x6 wood)
- 4x 4-arm post brackets (for 6x6 wood)
- 28x 2x6 rafter brackets for 7 roof rafters (2x6 wood)
- 48x 2x6 insert brackets for 24 wall slats (2x6 wood)
- Stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- NOTE: Wood (lumber) and anchoring hardware for securing the base brackets to a solid foundation are NOT included and will need to be purchased locally
This kit for a pergola with privacy shade walls will accommodate any stand-alone pergola ranging from 25-36 feet by 4-12 feet. The pergola does not need to be the exact dimensions shown in the images on this page.
The kit includes 28 2x6 rafter brackets so you can add 7 traditional roof rafters that cover all 3 roof sections and run longways (12' width with medium spacing). These rafters sit atop the beams and can be installed with or without overhangs. If you would like to space the rafters closer together, you can purchase additional 2x6 rafter brackets here. If you're wanting this same pre-configured pergola except with the roof rafters running the other direction (i.e. rotated 90 degrees so each roof section has 7 separate rafters), click here.
The pergola kit also includes 48 2x6 insert brackets. While the intent is that all 48 of these insert brackets be used to add 3 privacy walls with 8 2x6 slats each (all 8' height with medium spacing), you can use the brackets any way you'd like (i.e. adding another privacy wall or half/partial wall, adding a side railing, etc.). You can also purchase additional 2x6 insert brackets here.
About Our Steel 6x6 Pergola Brackets:
- Made with premium quality steel
- Made of 12-gauge steel (~2.6mm thick)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to brackets
- Made for dressed lumber commonly called 6x6s (actual dimensions are 5.5" x 5.5")
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- Reduces your pergola build time by as much as 75%
- Backed by our 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
