DIY Pergola Kit for 6x6 Wood Posts
⬩ Freestanding 4-Block pergola with a 6x6 Frame
⬩ Slatted Roof (Angled 2x6s)
About this Pergola Kit Configuration:
- Type: Free-standing (see the attached version of this kit)
- Bracket size: 6x6 (see the smaller 4x4 version of this kit)
- Roof style: Angled slats (see this same kit with an inline, traditional, or square posts roof)
- Privacy wall(s): None (see this same kit with 1 or 2 privacy walls)
- Rafter spacing: Far (see this same kit with medium or close rafter spacing)
Want something completely different? Use our easy design tool to create your own pergola configuration.
Included in this Pergola Bracket Kit:
-
9x base brackets (for 6x6 wood) - 4x 3-arm post brackets (for 6x6 wood)
- 4x 4-arm post brackets (for 6x6 wood)
- 1x 5-arm post bracket (for 6x6 wood)
- 88x 2x6 insert brackets for 44 roof/wall slats (2x6 wood)
- Stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- NOTE: Wood (lumber) and anchoring hardware for securing the base brackets to a solid foundation are NOT included and will need to be purchased locally
This kit will accommodate any free-standing pergola ranging from 13-24 feet by 13-24 feet, making it one of our most versatile pergola bracket kits. The pergola does not need to be the exact dimensions shown in the images on this page.
The DIY-friendly hardware kit includes 88 2x6 insert brackets. While the intent is that all 88 of these brackets be used to add 11 angled roof slats to each of the pergola's 4 roof sections (12' span each with far slat spacing), you can use the brackets any way you'd like (i.e. adding a privacy wall or half/partial wall, adding a side railing, increasing the number of slats in a roof/wall section, etc.). You can also purchase additional 2x6 insert brackets here.
Want a Smaller 4x4 Frame Instead?
Click here to see this same pergola bracket kit but for smaller 4x4 wood posts and 2x4 roof rafters (instead of 6x6 wood posts and 2x6 roof rafters).
About Our Steel 6x6 Pergola Brackets:
- Made with premium quality steel
- Made of 12-gauge steel (~2.6mm thick)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to brackets
- Made for dressed lumber commonly called 6x6s (actual dimensions are 5.5" x 5.5")
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- Reduces your pergola build time by as much as 75%
- Backed by our 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
About this Pergola Kit Configuration:
- Type: Free-standing (see the attached version of this kit)
- Bracket size: 6x6 (see the smaller 4x4 version of this kit)
- Roof style: Angled slats (see this same kit with an inline, traditional, or square posts roof)
- Privacy wall(s): None (see this same kit with 1 or 2 privacy walls)
- Rafter spacing: Far (see this same kit with medium or close rafter spacing)
Want something completely different? Use our easy design tool to create your own pergola configuration.
Included in this Pergola Bracket Kit:
-
9x base brackets (for 6x6 wood)
- 4x 3-arm post brackets (for 6x6 wood)
- 4x 4-arm post brackets (for 6x6 wood)
- 1x 5-arm post bracket (for 6x6 wood)
- 88x 2x6 insert brackets for 44 roof/wall slats (2x6 wood)
- Stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- NOTE: Wood (lumber) and anchoring hardware for securing the base brackets to a solid foundation are NOT included and will need to be purchased locally
This kit will accommodate any free-standing pergola ranging from 13-24 feet by 13-24 feet, making it one of our most versatile pergola bracket kits. The pergola does not need to be the exact dimensions shown in the images on this page.
The DIY-friendly hardware kit includes 88 2x6 insert brackets. While the intent is that all 88 of these brackets be used to add 11 angled roof slats to each of the pergola's 4 roof sections (12' span each with far slat spacing), you can use the brackets any way you'd like (i.e. adding a privacy wall or half/partial wall, adding a side railing, increasing the number of slats in a roof/wall section, etc.). You can also purchase additional 2x6 insert brackets here.
Want a Smaller 4x4 Frame Instead?
Click here to see this same pergola bracket kit but for smaller 4x4 wood posts and 2x4 roof rafters (instead of 6x6 wood posts and 2x6 roof rafters).
About Our Steel 6x6 Pergola Brackets:
- Made with premium quality steel
- Made of 12-gauge steel (~2.6mm thick)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to brackets
- Made for dressed lumber commonly called 6x6s (actual dimensions are 5.5" x 5.5")
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- Reduces your pergola build time by as much as 75%
- Backed by our 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
