Pergola Roof Rafter Bracket (for 6x6 Wood Posts)
Free Shipping - delivered by
-
Coupons - 1 available Reveal
Usage
Roof rafter brackets are used to create a traditional-style roof on top of the pergola beams (adding an upper 2nd layer to the pergola roof). The rafters inserted into and secured to these rafter brackets typically (but don't necessarily have to) extend 6-12 inches beyond the beams to create overhangs. Rafter brackets can be used with both free-standing pergolas and attached pergolas.
Steel Pergola Bracket Features
- Made with premium 12-gauge steel (~2.6mm thick)
- Made for dressed lumber commonly called 6x6s (actual dimensions are 5.5” x 5.5”)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to bracket
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into bracket
- Reduces your pergola build time by as much as 75%
- Backed by a 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
Dimensions & Specifications
- Width: 5.83 inches (148 mm)
- Depth: 5.5 inches (139.5 mm)
- Height: 5.5 inches (139.5 mm)
- Inner dimensions of sleeve (open at top): 5.63 x 5.5 inches (143 x 139.5 mm) - made for 6x6 wood post (which measure 5.5 x 5.5 inches)
- Holes on bottom plate (secured to beam): 4 (two on each end)
- Holes on one side wall: 4 (2x2 grid)
- Holes on opposite side wall: 0
- Hole size: 0.25 inch (6.35 mm) - ideal for #10 size screws (included)
- Weight: 5.25 pounds
- Not included: wood posts
Looking for a Complete Roof Kit?
Save time and money by purchasing a complete roof kit.
Other Brackets
Shop all 6x6 (and 2x6) pergola brackets OR all 4x4 (and 2x4) pergola brackets now.
Save by Buying a Full Pergola Kit
Save time and money by purchasing a full free-standing pergola kit or attached pergola kit instead of individual brackets.
Fast + Free Shipping
Shipping is free on all orders delivered within mainland USA. Shipping fees will apply for orders being delivered to Alaska, Hawaii & Canada. Click here for more details.
Although we reserve the right to use any carrier we choose, we typically ship products via UPS or USPS. All products ship directly from our Boise, ID warehouse within 1 business day!
Click here to learn more about how we handle returns.
Asssembly Information
Assembling a Zen Pergola is quite easy (even for novices) and only requires basic tools. Following these simple instructions, it should only take a couple hours for you and a helper to assemble your pergola.
5-Year Warranty
We stand behind our products! We will gladly replace any bracket that breaks, cracks, chips or corrodes within 5 years of purchase. Read more about our 5-year limited warranty.
Financing Available
Click here to learn about splitting your purchase up into 4 interest-free payments OR financing your order over up to 36 months.
