Kit for a Modern Pergola Attached to House - Any Size Up to 12' x 24'
⬩ Wall-Mounted 2-Block pergola with a 4x4 Frame
⬩ Slatted Roof (Straight Inline 2x4s) + 1 Privacy Wall
About this Pergola Kit Configuration:
- Type: Attached to house (see the free-standing version of this kit)
- Bracket size: 4x4 (see the larger 6x6 version of this kit)
- Dimensions: Up to 12' attached x 24' out from home (see the inverse up to 24' attached x 12' out from home version of this kit)
- Roof style: Straight inline rafters (see this same kit with a traditional, square posts or angled slats roof)
- Privacy wall(s): 1 (see this same kit with 0 or 2 privacy walls)
- Roof/wall slat spacing: Far (see this same kit with medium or close spacing)
Want something completely different? Use our easy design tool to create your own pergola configuration.
Included in this Modern Pergola Attached to House Kit:
-
4x base brackets (for 4x4 wood) - 2x wall-mount brackets (for 4x4 wood)
- 2x 3-arm post brackets (for 4x4 wood)
- 2x 4-arm post brackets (for 4x4 wood)
- 40x 2x4 insert brackets for 20 roof/wall slats (2x4 wood)
- Stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- NOTE: Wood (lumber) and anchoring hardware for securing the base brackets and wall-mount brackets are NOT included and will need to be purchased locally
This modern pergola attached to house kit will accommodate any wall-mounted pergola ranging from 4-12 feet wide (attached to the house) by 13-24 feet deep (out from the home). Click here to see a pergola kit with the dimensions flip-flopped.
The kit includes a total of 40 2x4 insert brackets. While the intent is that 20 of these brackets be used for adding 5 roof rafters to each of the 2 roof sections (12' span each with far slat spacing) and the remaining 20 be used for one privacy wall with 10 slats (8' height with far slat spacing), you can use the brackets any way you'd like (i.e. adding another privacy wall or half/partial wall, adding a side railing, increasing the number of slats in a roof/wall section, etc.). You can also purchase additional 2x4 insert brackets here.
Want a Larger 6x6 Frame?
Click here to see this same pre-configured modern pergola attached to house kit but with larger 6x6 wood posts and 2x6 roof and wall slats (instead of 4x4 wood posts and 2x4 roof and wall slats).
About Our Steel 4x4 Pergola Brackets:
- Made with premium quality steel
- Made of 14-gauge steel (~2.0mm thick)
- Laser-cut, bent and welded
- Advanced weather coating technology to withstand extreme weather conditions
- Pre-drilled holes for securing wood and accessories to brackets
- Made for dressed lumber commonly called 4x4s (actual dimensions are 3.5" x 3.5")
- Includes stainless steel screws (1.5-inch #10 self-tapping wood screws with pan/round head painted black) for securing wood into brackets
- Reduces your pergola build time by as much as 75%
- Backed by our 5-year warranty
- Shipped directly to your doorstep from Boise, Idaho
